China Car GPS Navigation DVD Player manufacturer

HD Color CCD Car DVR Camera Recorder For FORD MONDEO S - MAX KUGA FOCUS FIESTA

Product Details:
Place of Origin: CHINA
Brand Name: ISUDAR
Certification: CE, ROHS
Model Number: CA1300FO0008
Payment & Shipping Terms:
Minimum Order Quantity: 4pcs
Price: negotiation
Packaging Details: In carton
Delivery Time: 3-4days
Payment Terms: T/T, Western Union
Supply Ability: 1000pcs/day

Detail Information

Item Type: Car Reverse Camera Car Maker: Ford
Wire Or Wireless: Wired Material Type: ABS
Lens Material: Glass Degree: 170 Degree
High Light:

hd dvr dash cam

,

car video camera recorder

Product Description

 170 Wide Angle HD Color CCD Car DVR Camera Rear view Camera Waterproof for FORD MONDEO S-MAX KUGA FOCUS FIESTA





Specification:



Sensor:CCD
Effective Pixels: PAL: 728*582 NTSC: 728*492
Resolution: 480TV lines
Lens Angle: 120°
Working Power (DCV): 12V
Operation Temperature: -20°C+60°C RH95% Max
Storage Temperature: -30°C+60°C RH95% Max
Current Consumption: No more 300mA
Waterproof:IP67-68


Feature:



1. Condition:100% Brand new and high quality.
2. With waterproof function, durable
3. Easy install and simple operation
4. High clear camera read out, high-definition and wide viewing angles
5. Ensure your safe driving, to avoid any vehicle accidents



Installation Guide:



1. Take out your stock license plate light at the back of your car
2. Fix the camera to where the stock license plate light was
3. Connect the built-in license plate light of the camera to where the stock license plate light was connected to get the power
4. Connect the power of the camera to your reverse lights - red wire to positive and black wire to negative
5. Connect the video cable of the camera to the extension cord
6. Connect the extension cord to your car monitor
7. You will see the images when your car is in reverse shift.



Image sensor PC7070
Effective pixels 720*480 pixel
Video output 1.0VP-P,75 OHM
Scan System 2:1 interlace
Minimum illumination 0.01 Lux/F=1.2(0 Lux with IR on)
Operating Temperature -20℃~+75℃,RH95% MAX
Storage temperature -40℃ - 85℃,RH 95% MAX
TV System PAL/NTSC
Light perception area 3.584mm*2.688mm
Gamma coefficient 0.45
View Angle Level: 135° / Diagonal 170°
Horizontal Resolution 480 TV lines
Electronic Shutter 1-1/10000
White balance Auto
Waterproof IP67/68
Power supply DC 12V

HD Color CCD Car DVR Camera Recorder For FORD MONDEO S - MAX KUGA FOCUS FIESTA 0



HD Color CCD Car DVR Camera Recorder For FORD MONDEO S - MAX KUGA FOCUS FIESTA 1
